ACDC RD30 2CH Stand Alone Compatible Receiver

In stock

RPR100-003

Remote Pro®

$60.00
-
+

Free Untracked Shipping: 2-10 Business Days
Tracked Shipping: 1-5 Business Days
Express Shipping: 1-3 Business Days
Download Instructions



Frequency: 433.92 MHz

Capacity: 500 remotes

Channels: 2

Dimensions: 60W x 95H x 30D mm

Voltage: 12-24V

For compatible remotes for this receiver please Click Here

Please note: We recommend to have this receiver installed by a professional garage installer.

Terminal/Wiring Guide:

V+ (receiver) > usually called 12V, 24V V+ (motor)
GND (receiver) > usually called COM, Common, GND, 0V (motor)
CH1 - Left (receiver) > usually called PB, WB, OSC (motor)
CH1 - Right (receiver) > usually called COM, Common, GND, 0V (motor)

Please Note: Receivers are not included with instructions or wires and there will be no specific instructions on how to wire/connect this to your motor. You must cross reference the guide above with your motor manual. For easy DIY receiver upgrade, please refer to our receiver upgrade kits.

Please Note: All receiver are recommended to be installed by a professional
