- Open the package and remove the product along with all accessories.
- Unscrew the antenna by rotating it anticlockwise.
- Use the bracket's fixing hole to mark two holes on the wall.
- Drill two holes with a 6mm diameter and one hole with a 10mm diameter.
- Insert expansion plugs into the 6mm diameter holes. Thread the wires through the 10mm diameter hole.
- Route the power wire and antenna through the cable holes in the bracket, then secure the bracket to the wall using the provided 4mm x 30mm self-tapping screws.
- Feed the power wire and antenna through the cable holes in the bottom base. Attach the bottom base to the bracket using the supplied 4mm x 10mm screws.
- Connect the wire and antenna to their respective terminals.
- Reattach the cover, ensuring it fits snugly with the bottom base and leaves no gaps.
- Screw the antenna back in, turning it clockwise to tighten.
- Ensure that both the bracket and lamp are installed upright relative to the ground. Installing them horizontally could allow water to enter the lamp, potentially damaging the circuit board.
WARNING! This product may contain a button/coin cell battery. To prevent possible SERIOUS INJURY or DEATH:
- Keep new and used batteries out of reach of children at all times.
- Do not use the product if the battery compartment is damaged or doesn’t close securely.
- Dispose of used batteries immediately and safely - even flat batteries can cause harm.
- Do not ingest the battery. Chemical burn hazard.
- Act fast if you suspect a battery has been swallowed or inserted - severe or fatal injuries can occur within 2 hours.
- Seek immediate medical attention or call:
– Australia: Poisons Information Centre on 13 11 26
– New Zealand: National Poisons Centre on 0800 764 766
