Stoddart Compatible Receiver
In stock
RPR100-046
Remote Pro®
Stoddart Compatible Receiver
Frequency: 433.92 MHz
Capacity: 500 remotes
Channels: 2
Dimensions: 60W x 95H x 30D mm
Voltage: 12-24V
For compatible remotes for this receiver please Click Here
Please note: We recommend to have this receiver installed by a professional garage installer.
Terminal/Wiring Guide:
V+ (receiver) > usually called 12V, 24V V+ (motor)
GND (receiver) > usually called COM, Common, GND, 0V (motor)
CH1 - Left (receiver) > usually called PB, WB, OSC (motor)
CH1 - Right (receiver) > usually called COM, Common, GND, 0V (motor)
Please Note: Receivers are not included with instructions or wires and there will be no specific instructions on how to wire/connect this to your motor. You must cross reference the guide above with your motor manual. For easy DIY receiver upgrade, please refer to our receiver upgrade kits.
Please Note: All receiver are recommended to be installed by a professional
