Quick Set Up Guide:
1. Insert SIM into the receiver
2. Switch the power switch to on and ensure you have a solid light for power and a flashing light for SIM reception
3. SMS 1234TEL[phone number of SIM]# (do not write the brackets [] or text inside of the brackets - replace this with the actual phone number of the SIM - this is case sensitive)
4. SMS 1234ALL# (this will allow any mobile phone to call and activate the door)
5. Test by calling the mobile number
6. SMS 1234CC (this will operate the door via SMS)
Handy Tip: Check SIM card has reception and can make and receiver calls in a mobile
Handy Tip: All commands are case sensitive
Specifications
| GSM Frequency | Quad-band 850/900/1800/1900MHz |
| 3G/4G/NB-Iot | Optional: WCDMA/TDD-LTE/FDD-LTE/NB-IoT |
| Users | Up to 999 |
| Digital Input | 2 NC/NO dry contact |
| Digital Output | 1 Relay, 3A/240VAC |
| Siren Output | 12VDC/1A |
| DC Power supply | 9~24VDC/2A |
| Power consumption | 12V input Max. 50mA/Average 25mA |
| SIM Card | Supporting 3V SIM Card |
| Antenna | 50 Ω SMA Antenna interface |
| Temperature range | -20~+60 °C |
| Humidity range | Relative humidity 90% |
| Backup battery | 3.7V/900mAH |
| Exterior dimension | W88mm*D78mm*H32mm |
| Net Weight | 260 g |
Features
- Setup with easy to use PC Software
- Switches relay with free call from mobile phone
- 2 Digital inputs for sensors or switches
- SMS confirmation of relay switching
- Secure password protection
- No call charges (device will reject the call then operate the door)
- Only authorized numbers can operate the receiver (private numbers ignored)
- Operates from anywhere a 3G or 4G signal is available
- Open/close gates, doors, shutters, garage doors, bollards, boom gates & access doors
- Security alarm, on/off lights, pumps and machines
Compatibility
- GSM/3G/4G Network Compatible
- Text To Operate: Optus & Telstra, Vodafone
-
Call To Operate: Optus & Telstra
- App Available - Android Only (Search RTU5025)
Set Up/Configuration Options
- SMS Command
- Android App (Search 3G Gate Opener RTU5025)
- PC Software
